iEcho MCT Rotary Die Cutter

The MCT Series Rotary Die Cutter offers intelligent die-cutting for small batch and repeat production. Compact and easy to operate, this die cutting machine excels in producing self-adhesive stickers, wine labels, garment hangtags, playing cards, and more. It serves various industries, including printing, packaging, clothing, and electronics.

Equipped with a fish-scale feeding platform, the MCT die cutting machine ensures fast and precise sheet alignment. High-strength rolls with magnetic blades enable seamless die-cutting processes, including full-cutting, half-cutting, perforating, creasing, and easy-tear lines. This advanced design guarantees efficient production without compromising quality.

Automatic Feeding System

The paper feeds through a tray lifting mechanism and is peeled from top to bottom using a vacuum suction cup belt. It is then transported to the automatic deviation correction conveyor line for precise alignment.

Correction System

The paper feeds through a tray lifting mechanism and is peeled from top to bottom using a vacuum suction cup belt. It is then transported to the automatic deviation correction conveyor line for precise alignment. At the bottom of the automatic deviation correction conveyor line, the belt operates at a specific deviation angle to guide the paper. The adjustable driving belt ensures smooth forward movement, while pressure from the balls increases friction for secure paper transport.

Die Cutting System

The high-speed rotating flexible die-cutting knife on the magnetic roller precisely cuts the desired pattern shape.

Waste Rejection System

After rolling and cutting, the paper passes through a waste rejection device. This device efficiently removes wastepaper, with adjustable width settings to match the pattern dimensions.
