Mimaki UCJV300 Series UV-LED Print & Cut Inkjet Printer

The Mimaki UCJV300 Series is a versatile and innovative UV-LED print-and-cut solution designed to elevate your sign and graphics business. Combining high-quality printing with precision cutting, this series offers unparalleled flexibility and efficiency for various applications.

Key Features:

Multilayer Printing: The UCJV300 Series supports advanced 4-layer and 5-layer printing capabilities. The 4-layer "Day & Night Printing" allows for dynamic image transitions when backlit, creating captivating displays that change from day to night. The 5-layer "Front & Back Printing" enables different designs to appear on either side of transparent media, perfect for window graphics and double-sided signage.
Immediate Finishing: Utilizing UV-LED technology, prints cure instantly, eliminating drying time. This means you can move directly to cutting, finishing, or installation, significantly reducing production time and increasing workflow efficiency.
Eco-Friendly UV Inks: The UCJV300 Series uses newly developed, environmentally friendly UV inks, including the LUS-170 and LUS-175 options. These inks are GREENGUARD Gold certified, ensuring they meet stringent chemical emissions standards, making them safe for use in sensitive environments like schools and hospitals.
Integrated Cutting Functions: The innovative "ID Cut" function enhances efficiency by automating the cutting process, reducing errors, and saving time.
Flexible Media Handling: Capable of printing on a wide range of materials, including banners, vinyl, transparent PET, and paper, this series expands your creative possibilities.

Specifications:

Print Resolutions: Offers multiple resolutions—300dpi, 600dpi, 900dpi, and 1200dpi—to cater to various quality requirements.
Ink Options: Compatible with LUS-170, LUS-175, and LUS-200 UV inks, available in colors including Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, White, and Clear.
Print Widths: Available in four models to suit different needs:
- UCJV300-75: Maximum print/cut width of 800 mm (31.5").
- UCJV300-160: Maximum print/cut width of 1,610 mm (63.4").

The Mimaki UCJV300 Series is engineered to meet the diverse demands of the sign and graphics industry, offering a comprehensive solution that combines quality, efficiency, and environmental responsibility. Whether you're producing vibrant banners, intricate window graphics, or dynamic backlit displays, the UCJV300 Series delivers exceptional results to help your business stand out.

		UCJV300-75	UCJV300-160
Print head		On-demand piezo head
Print resolution		300dpi, 600dpi, 900dpi, 1200dpi
Droplet size		Min. 7pl, Max. 28pl
Head gap		3 degrees adjustment (2.0/2.5/3.0 mm) by manual
Ink	Type/Color	LED-UV ink: LUS-170 (C, M, Y, K, Lc, Lm, W, Cl)
		LED-UV ink: LUS-175 (C, M, Y, K, Lc, Lm, W, Cl) *Only available in specific countries
		LED-UV ink: LUS-200 (C, M, Y, K, W)
	Capacity	1L (Bottle supply)
Max. print width		800 mm (31.5 in)	1,610 mm (63.4 in)
Max. media width		810 mm (31.9 in)	1,620 mm (63.8 in)
Media thickness		1.0 mm or less
Media roll outer diameter		φ250 mm or less
Media roll weight		40 kg (88.2 lb) or less
Cut speed		Max. 300 mm/s (420 mm/s in 45 degrees direction)
Cut pressure		10-450 gf
Cutter Types		Eccentric cutter, Blade for small character, Blade for reflective sheet, Blade for fluorescent sheet, Blade for PVC with low-pressure
Safety standard		VCCI Class A / FCC Class A / Compliant with UL 60950-1, ETL / CE Marking (EMC, Low voltage, Machinery directive) / RoHS / CB Report / REACH, ENERGY STAR® / RCM
Interface		USB2.0 / Ethernet 1000 BASE-T
Power supply		Single phase (AC100-120 / 200-240V±10%, 50/60Hz±1Hz)
Power consumption		AC100V: 1.44kW / AC200V: 1.92kW
Operational environment		Temperature: 20-30°C / 68-86⁰F Humidity: 35-65% Rh (Non-condensing)
Dimensions (W×D×H)		2,090 x 776 x 1,475 mm (82.3 x 30.6 x 58.1 in)	2,900 x 776 x 1,475 mm (114.2 x 30.6 x 58.1 in)
Weight		144 kg (317.5 lb)	188 kg (414.5 lb)
